9XSeries

9X Series Motion Controller



1-3 Axis in 3U 1/2 rackmount

1-6 Axis in 3U 19" rackmount

4.3" Color Touchscreen

Recipe and setpoint editing

USB, RS232, RS485, Ethernet Interfaces



NEW!!!    Adaptive Torque Control

  • Advanced Motion Controllers with Adaptive Torque Control

    9X Series motion controllers provide real-time motor phase current adjustments to compensate for load variance. The operator simply sets the maximum current for the application and a load variable that indicates a motor stall. Easily find mechanical hard stops for sensorless operation, or use Adaptive Torque Control to achieve as much as 50% in energy savings.

    In the example below, the maximum current is set at 70%. The controller automatically determines phase currents and adjusts in real-time. On this lead screw application, only a peak current setting of 35% is needed during start-up. The run current at speed is reduced to 10% of maximum. At step 1150, the lead screw exhibits some resonance which requires 25% of maximum to avoid a stall condition. The controller then returns to a run current of 10%.




    Lead Screw Example
